Single Mode 24 Core ADSS Communication Cable , All Dielectric Fiber Optic Cable

Minimum Order Quantity : 1KM Packaging Details : wooden drum
Delivery Time : 3-5 working days ,it depends on your order Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability : 60000KM/month
Place of Origin: Guangdong, China Brand Name: Jiqian
Certification: ISO9001 Model Number: ADSS

Detail Information

Fiber Count: 2-144 Core Lift Time: 25 Years
Fiber Type: G652D Application: Overhead
OEM: Yes Jacket: PE
Color: Black
High Light:

24 Core ADSS Communication Cable

,

Single Mode ADSS Communication Cable

,

ADSS All Dielectric Fiber Optic Cable

Product Description

8 10 12 24 Core ADSS Communication Cable Single Mode Overhead All Dielectric Fiber Optic Cable
Single Mode  24 Core ADSS Communication Cable , All Dielectric Fiber Optic Cable 0
Fiber parameter

ItemUnitSpecification
Fiber TypeG.652D
Mode field diameter1310nmmm9.2±0.4
 1550nmmm10.4±0.8
Cladding diametermm125.0±1
Cladding non-circularity%£1.0
Core/cladding concentricity errormm£0.5
Coating diametermm245±5
Coating non-Circularity%£6.0
Coating/cladding concentricity errormm£12.0
Cable cut-off wavelengthnm£1260
Attenuation Coefficient1310nmdB/km£0.36
 1550nmdB/km£0.22
Proof stress levelkpsi≥100

Single Mode  24 Core ADSS Communication Cable , All Dielectric Fiber Optic Cable 1
Dimensions of Cable Constructions

Fiber countStructureFibers per tube

Loose tube diameter

(mm)

CSM diameter/pad diameter

(mm)

Nominal Thickness of outer jacket

(mm)

Cable diameter/

Height

(mm)

Cable weight

(kg/km)

41+641.9±0.12.0/2.01.69.8±0.282
61+662.0±0.12.0/2.01.69.8±0.282
81+641.9±0.12.0/2.01.69.8±0.282
121+662.1±0.12.0/2.01.69.8±0.282
241+662.1±0.12.0/2.01.69.8±0.285
361+6122.2±0.12.0/2.01.610.0±0.285
481+6122.2±0.12.0/2.01.610.0±0.288
721+6122.2±0.12.0/2.01.610.5±0.398
961+8122.2±0.12.0/3.41.711.8±0.3123
1441+12122.2±0.13.0/7.21.715.2±0.3175

Single Mode  24 Core ADSS Communication Cable , All Dielectric Fiber Optic Cable 2
Factory
Single Mode  24 Core ADSS Communication Cable , All Dielectric Fiber Optic Cable 3
We are the factory, having quality control.
We privide you factory price.You can save costs, having good quality.
Single Mode  24 Core ADSS Communication Cable , All Dielectric Fiber Optic Cable 4
Package: Wooden reel, 1000m/reel, 2000m/reel, 3000m/reel, customer's requirements are also welcomed

Single Mode  24 Core ADSS Communication Cable , All Dielectric Fiber Optic Cable 5
We go to exhibitions. We have rich foreign trade experience, you can save purchasing time.
Don't hesitate to contact me. Whatsapp:+86 18122383351

FQA

1,Q:Are you a factory or trade company?
A:We are a factory

2,Q:What is the MOQ?
A:The MOQ of Fiber Optic cable is 1km.

3.Q:Which brand of fiber do you use?
A:YOFC,Fiberhome,etc

4,Q:Can you accept small order?
A:Yes, small order is available .We support new project of our customers as we know business is always from small order.

5,Q:What’s delivery time?
A:The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.

6.Can you supply customized products and logo?
A:Yes. We supply OEM service.

7.What’s your payment terms?
A: We accept T/T,L/C,Western Union, 30% Deposit and 70% before shipment.
