Detail Information

Place Of Origin: Guangzhou,China Brand Name: Jiqian
Certification: ISO9001 Model Number: GYTS
Number Of Conductors: ≥ 10 Fiber Count: 4-288 Cores
Installation: Conduit/Aerial Strength Member: Central: Steel Wire Or FIberglass Reinforced Plastic (FRP)
Manufacturer: Yes
High Light:

GYTS Duct Fiber Optic Cable

,

SDOC Duct Fiber Optic Cable

,

48 Core Fiber Optic Cable

Product Description

GYTS 48 core Single mode Outdoor Duct Armored Fiber Optic Cable



Product Construction

Fiber:2-288 fiber Multi-loose tube gel-filled

Central Strength Member:Fiberglass reinforced Platic (FRP) or steel wire.

Armor:Corrugated steel tape

Outer Jacket:Black UV Polyethylene(PE)

GYTS 48 Core Single Mode Armored Duct Fiber Optic Cable 0

Product Detail
1. Good mechanical and temperature performance
2. High strength loose tube that is hydrolysis resistant
3. Special tube filling compound ensure a critical protection of fiber
4. Specially designed compact structure is good at preventing loose tubes from shrinking
5. Crush resistance and flexibility
6: PE sheath protects cable from ultraviolet radiation
7. The following measures are taken to ensure the cable watertight:
8. Steel wire used as the central strength member
9. Loose tube filling compound
10. 100% cable core filling
11. PSP enhancing moisture-proof



Product Description
Item
GYTA GYTS 48 Cores Single Mode Fiber Optic Cable


Feature
1. Choice of fiber type
2. Color code of fiber
3. High water & crush resistance
4. Choice of sheath material
5. Low attenuation and dispersion
6. Good flexibility and bending performance
Application
Suitable for external application in duct and aerial
Structure Characters
1. Metallic strengthen member (Phosphated steel wire)
2. Steel taoe under PE sheath
Temperature
1. Operating temperature: -20℃ to 70℃
2. Storage temperature: -20℃ to 70℃



Technical Data

Fiber

Count

Nominal

Diameter

(mm)

Nominal

Weight

(kg/km)

Max Fiber Per Tube Max No. of (Tubes+fillers)

Allowable Tensile Load

(N)

Allowable Crush Resistance (N/100mm)
Short Term Long Term Short Term Long Term
2~36 10.7 132 6 6 1500 600 1000 300
38~72 12.0 165 12 6 1500 600 1000 300
74~96 13.8 204 12 8 2000 600 1000 300
98~120 15.3 240 12 10 2000 600 1000 300
122~144 17.0 284 12 12 2500 600 1000 300
146~216 17.1 285 12 18(2 layers) 2500 600 1000 300
218~288 19.5 350 12 24(2 layers) 3000 600 1000 300





GYTS 48 Core Single Mode Armored Duct Fiber Optic Cable 1

Certification

GYTS 48 Core Single Mode Armored Duct Fiber Optic Cable 2

Comparison

GYTS 48 Core Single Mode Armored Duct Fiber Optic Cable 3



Packing

GYTS 48 Core Single Mode Armored Duct Fiber Optic Cable 4





FAQ:



1,Q:Are you a factory or trade company?
A:We are a factory


2,Q:What is the MOQ?

A:The MOQ of Fiber Optic cable is 1km.



3.Q:Which brand of fiber do you use?

A:YOFC,Fiberhome,etc



4,Q:Can you accept small order?
A:Yes, small order is available .We support new project of our customers as we know business is always from small order.


5,Q:What’s delivery time?
A:The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.



6.Can you supply customized products and logo?

A:Yes. We supply OEM service.



7.What’s your payment terms?

A: We accept T/T,L/C,Western Union, 30% Deposit and 70% before shipment.
