Home /Products/Aerial Fiber Optic Cable/Hybrid 24 Cores Aerial Fiber Optic Cable ADSS Type

Hybrid 24 Cores Aerial Fiber Optic Cable ADSS Type

1km
MOQ
Hybrid 24 Cores Aerial Fiber Optic Cable ADSS Type
Features Gallery Product Description Request A Quote
Features
Specifications
Jacket Material: PE
Outer Diameter: 9mm
Fiber Count: 4-144 Core
Structure: Unit Tube/Stranded Twisted Cable
Strength Member: Steel Tape
Product Name: Hybrid Optic Fiber Cable
Fiber Type: YOFC Or As Request
Application: Aerial,Duct
Color: Black
Type: Hybrid Cable
Length: 2km Or Customized Length
Highlight:

24 Cores Aerial Fiber Optic Cable

,

Hybrid Aerial Fiber Optic Cable

,

v adss fiber cable
Basic Infomation
Place of Origin: Guangzhou China
Brand Name: JQ/OEM
Certification: ISO9001 ROHS CE FCC
Model Number: GYDTS/GYDTA
Payment & Shipping Terms
Packaging Details: 1/2/3/4/5 km in one wooden drum
Delivery Time: 3-5 dyas
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30km Per day
Product Description

Hybrid Composite Copper Wire 24 Cores Fiber Optic Cable




Applications:
1.Used in outdoor applications that require both optical fiber and copper wire elements for communication and power
2.Copper wire can power remote electronics used in fiber optic communications
3.Copper wire can also be used for low data rate data transmission
4.Deployable cables have been used in network and private broadcast applications around the world
5.Cables can be designed for your custom applications
Standards:
YD/T 901 / IEC 60794-3-10

Temperature Range:
Transportation:
-40℃~+70℃
Installation:
5℃~+50℃
In use:
In use:-40℃~+70℃







Optical Characteristics

Item Specification
Fiber type G.652D
Attenuation
@ 1310 nm ≤0.36 dB/km
@ 1383 nm ≤0.35 dB/km
@ 1550 nm ≤0.22 dB/km
@ 1625 nm ≤ 0.30 dB/km
Cable Cut-off Wavelength(λcc) ≤1260 nm
Zero Dispersion Wavelength(nm) 1300 ~ 1324 nm
Zero Dispersion Slope ≤0.092 ps/(nm2.km)
Chromatic Dispersion
@ 1288 ~ 1339 nm ≤3.5 ps/(nm. km)
@ 1550 nm ≤18 ps/(nm. km)
@ 1625 nm ≤22 ps/(nm. km)
PMDQ ≤0.2 ps/km1/2
Mode Field Diameter @ 1310 nm 9.2±0.4 um
Core Concentricity Error ≤0.6 um
Cladding Diameter 125.0±0.7 um
Cladding Non-circularity ≤1.0%
Coating Diameter 245±10 um
Proof Test 100 kpsi (=0.69 Gpa), 1%







Technical Parameters

Range of Temperature -20c~ +60c
Riser Type OFNR/OFN FT4
Plenum Type OFNR/OFN FT6
Jacket LSZH or PE
Code name cable
cores		 Diameter
(mm)		 Copper
Wire
(mm)		 Linear
mass
(kgk
m)		 Tensile Crush Bending
radius
Short
Term
(N)		 Long
Term
(N)		 Short
lerm
N)		 Long
Term
(N)		 short
Term
N)		 Long
Term
(N)
OPLC-2*0.5 6~24 10 2*0.5 125 1500 600 1000 300 20D 10D
OPLC-4*0.5 6-~24 10 4*0.5 130 1500 600 1000 300 20D 10D
OPLC-2*0.75 6~24 10 2*0.75 128 1500 600 1000 300 20D 10D
OPLC-4*0.75 6~24 10 4*0.75 135 1500 600 1000 300 20D 10D
oPLC-2*1.0 6~24 10 2*1.0 130 1500 600 1000 300 20D 10D
OPLC-4*1.0 6-~24 12 4*1.0 150 1500 600 1000 300 20D 10D
OPLC-2*1.5 6~24 12 2*1.5 140 1500 600 1000 300 20D 10D
OPLC-4*1.5 6~24 12 4*1.5 160 1500 600 1000 300 20D 10D
OPLC-2*2.5 6~-24 12 2*2.5 150 1500 600 1000 300 20D 10D
OPLC-4*2.5 6-~24 14.5 4*2.5 180 1500 600 1000 300 20D 10D





Product Image

Hybrid 24 Cores Aerial Fiber Optic Cable ADSS Type 0







Packing&Delivery



1/2/3/4/km in one wooden drum,deliver days:3-7work days

Hybrid 24 Cores Aerial Fiber Optic Cable ADSS Type 1

Hybrid 24 Cores Aerial Fiber Optic Cable ADSS Type 2



FAQ

Q1.About the price?
Re.We usually quote within 12 hours after we confirm the technical data of your products.

Q2.What's the payment method?
Re.We accept L/C,T/T,Western Union,MoneyGram,PayPal etc.



Q3.What are your terms of payment?
Re.30% in advance,and 70% before shipment

Q4.How to ship the items to me?
Re.Courier(DHL,TNT,FEDEX,UPS,EMS),Airfreight,Ocean Ship are available.

Q5.How long is your delivery time?
Re.The general delivery time is 5-7 days after order confirmed,it depends on the order quantity.

Q6.Can you send me a free sample?
Re.Yes,We are willing to send free sample,if you would like to pay the shipping costs.

Q7.Do you accept OEM or ODM?
Re.Yes,we're factory. any your customized requirements we can do our best to help you realize.
