GYXTW Uni Tube Fiber Cable Optical 4 Core 12 Core 24 Core Single Mode Fiber Optic Cable

Minimum Order Quantity : 1km Packaging Details : wooden drum/customized
Delivery Time : 2-4days Payment Terms : Western Union, MoneyGram, T/T, L/C
Supply Ability : 100km per Month
Place of Origin: CHINA Brand Name: jiqian
Certification: ISO9001 Model Number: ADSS 96core 144core

Detail Information

Fiber Type: G652D Application: Aerial/duct
Number Of Conductors: 96core Structure: Stranded Loose Tube
Operating Temperature: -40 ~ +60 C Central Strength Member: FRP
Span: 80m 100m 200m 300m
High Light:

GYXTW Uni Tube Fiber Cable

,

12 Core Uni Tube Fiber Cable

,

12 Core Fiber Optic Cable

Product Description

GYXTW Uni Tube Fiber Cable Optical Price 4 Core 12 Core 24 Core Single Mode Fiber Optic Cable

Excellet mechanical and environmental performance. Stainless steel or gaivanized steel self-supporting. Excellent mechanical and temperature performance.
Critical protection to fibers.
The following measures are taken to ensure the water blocking performance of the cable:
- Single steel wire used as the central strength member
- Special water-blocking filling compound in the loose tube
-1 00% cable core filling good

GYXTW Uni Tube Fiber Cable Optical 4 Core 12 Core 24 Core Single Mode Fiber Optic Cable 0
GYXTW Uni Tube Fiber Cable Optical 4 Core 12 Core 24 Core Single Mode Fiber Optic Cable 1
GYXTW Uni Tube Fiber Cable Optical 4 Core 12 Core 24 Core Single Mode Fiber Optic Cable 2
GYXTW Uni Tube Fiber Cable Optical 4 Core 12 Core 24 Core Single Mode Fiber Optic Cable 3

Technical Data:



Cable fiber count
/
2~30
32~60
62~72
Structure
/
1+5
1+5
1+6
Fiber style
/
G.652D
Central strength member
material
mm
FRP
Diameter (average)
1.5
1.5
2.1
Loose Tube
Material
mm
PBT
Diameter (average)
1.8
2.1
2.1
Thickness(average)
0.32
0.35
0.35
Max fiber/loose tube
6
12
12
Tubes color
Full color identification
Fiber excess length
%
0.7~0.8
Water resistance
Material
/
Cable jelly
Inner sehath
material
mm
MDPE
Inner sheath
0.9mm
Non-metallic strengthen components
Material
/
Aramid Yarn
Outer sheath
material
mm
MDPE
Outer sheath
1.8mm
Cable diameter(average)
mm
10.9
11.5
12.1
Cable weight (Approximate)
kg/km
95
110
120
Cable Sectional area
mm2
93.31
103.87
114.99
Attenuation coefficient(Max)
1310nm
dB/km
0.35
1550nm
0.21
Rated Tensile Strength(RTS)
kn
6
Max allowed tension( MAT)
kn
2.5
Annual average operating tension (EDS)
kn
3.2
Young's modulus
kn/mm2
7.8
Coefficient of thermal expansion
10-6/℃
9
Crush resistance
Long term
N/100mm
1100
Short term
2200
Permission Bent Radius
static
mm
15 of OD
dynamic
20 of OD

Packing details:

1.1-3km/wooden reel,other lengths of the cable are also available as per the buyer's requirements

1.One wooden reel of the cable packed in a carton

The time of shipping:1-500km will be shipped in eight days,above 500km can be negotiated about

GYXTW Uni Tube Fiber Cable Optical 4 Core 12 Core 24 Core Single Mode Fiber Optic Cable 4

FAQ:

1. Are you the real manufacturer?
Yes, we are factory in guangzhou china, welcome to visit us!

2. what is your minimum quantity?
1KM. We support new project of our customers, trial order is available


3.Can I get a sample?
Yes, we provide FREE sample and you just need to pay for express freight.


4.What about Payment?

L/C,T/T,Western Union and Paypal are acceptable.


5.Delivery time?

Generally 3-7 working days, also it is according to qty.


6.Can you supply customized products and logo?
Yes, we supply OEM&ODM service, pls feel free to contact.



7.Which brand of fiber do you use?

Corning,YOFC,Fiberhome,etc
