Home ProductsADSS Fiber Optic CableFactory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable
Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable
Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable
Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable
Contact Now

Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable

Minimum Order Quantity : 1kilometer Packaging Details : Wooden Drum
Delivery Time : 2-4 days Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability : 80000 kilometers per month
Place of Origin: China Brand Name: JQ\OEM
Certification: CE/ISO9001 Model Number: ADSS

Detail Information
Place Of Origin: Guangdong,China Fiber Core: 2-288 Core
Jacket: PE Or As Your Need Certification: CE/ISO9001
Storage/Transport Temperature Range: -40℃ To +60℃ Number Of Conductors: ≥ 10
Package: Wood Drum MOQ: 1KM
Strength Member: FRP Keyword: ADSS
Length Per Roll: 2km/3km/4km
Highlight:

12 core ADSS Fiber Optic Cable

,

24 core ADSS Fiber Optic Cable

,

12 24 48 core ADSS Cable

Product Description

Fiber parameter

Item Unit Specification
Fiber Type G.652D



Mode field diameter

 1310nm mm 9.2±0.4
1550nm mm 10.4±0.8
Cladding diameter mm 125.0±1
Cladding non-circularity % ≤1.0
Core/cladding concentricity error mm ≤0.5
Coating diameter mm 245±5
Coating non-Circularity % ≤6.0
Coating/cladding concentricity error mm ≤12.0
Cable cut-off wavelength nm ≤1260



Attenuation Coefficient

 1310nm dB/km ≤0.36
1550nm dB/km ≤0.22
Proof stress level kpsi ≥100

Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable 0



Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable 1
Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable 2
Product packaging
Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable 3

Packing :

Each single length of cable shall be reeled on Fumigated Wooden Drum suitable for long distance shipment.

Sealed by strong wooden battens.

At least 1 m of inside end of cable will be reserved for testing.



Total quantity is at least the ordered quantity



Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable 4
100% Wood Reel
100% wood reel , fumigation label, safe, environmentally friendly and can be recycled
Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable 5
Cable Rolling
Different dia of wood drum suit for different distance , from 2km to 5km
Factory Price All Dielectric Self-Supporting 12 24 48 core ADSS single jacket optical fiber cable 6
Solid Wood Package
The packaging is firm and can be applied to complex geographical environment construction

Payment:

We usually use T/T

T/T deposit before production and balance when shipment.
