Premium ADSS Double Sheath Fiber Optic Cable Span 400m 24 48 72 96 144 288 Core
Contact Person : Lillian
Phone Number : +8618122384553
whatsapp : +8618122384553
| Minimum Order Quantity : | 1km | Packaging Details : | Wooden drum |
|---|---|---|---|
| Delivery Time : | 3-5 days,it depends on order quantity | Payment Terms : | L/C, T/T, Western Union,Alipay |
| Supply Ability : | 9000km per month |
| Place of Origin: | China | Brand Name: | Jiqian |
|---|---|---|---|
| Certification: | ISO 9001/CE/ROHS/FCC | Model Number: | ADSS-48B1 |
|
Detail Information |
|||
| Place Of Origin: | Guangzhou,China | Cable Brand: | Jiqian |
|---|---|---|---|
| Number Of Conductor: | ≥ 10 | Cettification: | ISO 9001/CE/ROHS/FCC |
| Manufacturer: | Yes | Application: | Overhead |
| Outer Sheath: | PE | Number Of Fiber: | 2-576 |
| Length: | 2/3/4/5km One Drum,option | Fiber Brand: | Fiberhome/YOFC/Corning |
| High Light: | FCC Optical Fiber Cable,ADSS Outdoor Optical Fiber Cable |
||
Product Description
Fiber Optic G652D:
| Item | Unit | Specification | |
| Fiber Type | G.652D | ||
| Mode field diameter | 1310nm | mm | 9.2±0.4 |
| 1550nm | mm | 10.4±0.8 | |
| Cladding diameter | mm | 125.0±1 | |
| Cladding non-circularity | % | ≤1.0 | |
| Core/cladding concentricity error | mm | ≤0.5 | |
| Coating diameter | mm | 245±5 | |
| Coating non-Circularity | % | ≤6.0 | |
| Coating/cladding concentricity error | mm | ≤12.0 | |
| Cable cut-off wavelength | nm | ≤1260 | |
| Attenuation Coefficient | 1310nm | dB/km | ≤0.35 |
| 1550nm | dB/km | ≤0.22 | |
| Proof stress level | kpsi | ≥100 | |
All of our fiber cables have to be tested before sending out
from our factory
Pemium optical fiber cables with 30 years life expectancy
