Stranded Loose Tube 2km GYTY53 Direct Burial Armored Cable

1000m
MOQ
Stranded Loose Tube 2km GYTY53 Direct Burial Armored Cable
Features Gallery Product Description Request A Quote
Features
Specifications
Fiber Type: G652D
Oem: Available
Application: Telecom/network
Number Of Conductors: 4-144core
Structure: Stranded Loose Tube
Operating Temperature: -40 ~ +60 C
Cable Diameter:: 9.6mm
Packing: 2km/Wooden Drum
Highlight:

GYTY53 Direct Burial Armored Cable

,

2km Direct Burial Armored Cable

,

GYTY53 stranded loose cable
Basic Infomation
Place of Origin: Guangzhou
Brand Name: JQ/OEM
Certification: ISO9001 ROHS CE-EMC FCC SDOC
Model Number: GYFTY53 GYTY53
Payment & Shipping Terms
Packaging Details: wooden drum
Delivery Time: 2-4day
Payment Terms: Western Union, T/T, L/C
Supply Ability: 100km per 2 day
Product Description



GYFTY53 Stranded Loose Tube Armored Cable
The fibers, 250µm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire locates in the center of core as a strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular core. Then the cable core is covered with a thin polyethylene (PE) inner sheath, which is filled with jelly to protect it from water ingress. A layer of water-blocking material is applied around the cable core to prevent water ingress all the same. After a corrugated steel tape armor is applied, the cable is completed with a PE outer sheath
Stranded Loose Tube 2km GYTY53 Direct Burial Armored Cable 0

Characteristics

· Good mechanical and temperature performance
· High strength looes tube that is hydrolysis resistant
· Special tube filling compound ensure a critical protection of fiber

· Crush resistance and flexibility
· The following measures are taken to ensure the cable watertight:

- Steel wire used as the central strength member
- Loose tube filling compound

- 100% cable core filling- APL moisture barrier

- PSP enhancing moisture-proof Water-blocking material

Standard

GYTY53 cable complies with Standard YD/T 901-2001as well as IEC 60794



Storage/Operating Temperature

-40℃ to + 70℃



Application



Underground Direct burial





Dimensions of cable constructions



Fiber count

 Structure Fibers per tube

Loose tube diameter

(mm)

diameter/pad diameter

(mm)

Thickness of

Inner jacket

(mm)

Thickness of

outer jacket

(mm)

Cable diameter

(mm)

Cable weight

(kg/km)
12 1+6 6 1.8 ±0.1 2.2 /2.2 0.9±0.1 1.6±0.1 12.4 ±0.5 138
24 1+6 6 1.8 ±0.1 2.2 /2.2 0.9±0.1 1.6±0.1 12.4 ±0.5 140
48 1+6 12 2.0±0.1 2.3 /2.3 0.9±0.1 1.6±0.1 12.9 ±0.5 152
96 1+8 12 2.0±0.1 2.6/3.5 0.9±0.1 1.6±0.1 14.1 ±0.5 182
144 1+12 12 2.0±0.1 3.0 /6.3 0.9±0.1 1.6±0.1 16.9 ±0.5

256





Packing detail

Stranded Loose Tube 2km GYTY53 Direct Burial Armored Cable 1



Stranded Loose Tube 2km GYTY53 Direct Burial Armored Cable 2

Stranded Loose Tube 2km GYTY53 Direct Burial Armored Cable 3
