Anti-Rodent Fiber Optic Cable 48 96 144 Core Fiber Optic GYTS Armored Optical Fiber Cable

Product Description

Anti-Rodent Fiber Optic Cable 48 96 144 Core Fiber Optic GYTS Armored Optical Fiber Cable

Fiber Optic G652D



Item		Unit	Specification
Fiber Type			G.652D
Mode field diameter	1310nm	μm	9.2±0.4
	1550nm	μm	10.4±0.8
Cladding diameter		μm	125.0±1
Cladding non-circularity		%	≤1.0
Core/cladding concentricity error		μm	≤0.5
Coating diameter		μm	245±5
Coating non-Circularity		%	≤6.0
Coating/cladding concentricity error		μm	≤12.0
Cable cut-off wavelength		nm	≤1260
Attenuation Coefficient	1310nm	dB/km	≤0.36
	1550nm	dB/km	≤0.22
Proof stress level		kpsi	≥100

Cable performance:

Item		Parameters
Fiber Count		96
No. of Fiber per tube	Dimension	250µm±15µm
	12 fibers	Color
		Blue,Orange,Green,Brown,Gray,Natural,Red,Black,Yellow,Purple,Pink,Aqua
Loose tube	Dimension	2.2±0.1mm
	Material	PBT
	8 loose tubes	Blue,Orange,Green,Brown,Gray,Natural,Red,Black,
Filler	Material	PE
	Color	Black
Central Strength Member	Dimension	1.6/3.5mm
	Material	Phosphating steel wire
Armoured	Material	Plastic coated steel strip/Aluminium
Outer jacket	Material	HDPE/LSZH
	Color	Black



Company profile:



1.Located in Guangzhou China

2.12 years experiance of producing fiber optic cable

3.CE/ROSH/FCC/ISO9001 Certifications

4.Exporting fiber optic cable to all over the world



Exhibition



Certification:





FAQ:



Q1.What is your terms of packing?

A: Generally, we pack our goods in drum with pallet for export.2KM/3KM/4KM/5KM of one drum or as per your requirements



Q2. What is your terms of payment?

A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages

before you pay the balance.



Q3. What is your terms of Trade?

A: EXW, FOB, CFR, CIF



Q4. How about your delivery time?

A: Generally, it will take 5 to 7days after receiving your initial. The specific delivery time depends

on the items and the quantity of your order.



Q5. Can you provide OEM or ODM

A: Yes



Q6. What is your sample policy?

A: We provide FREE sample if we have them in stock



Q7. Do you test all your goods before delivery?

A: Yes, all of cables have to be tested before delivery



Q8: How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers benefit ;

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
