Self Supporting 48 Core Aerial Optical Fiber Cable Gytc8s
Contact Person : Philip
Phone Number : +8613422342788
whatsapp : +8613422342788
| Minimum Order Quantity : | 1 Kilometer | Packaging Details : | Wooden Drum |
|---|---|---|---|
| Delivery Time : | 2-5days | Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 8000 kilometers per month |
| Brand Name: | JQ/OEM | Certification: | CE/ISO9001 |
|---|
|
Detail Information |
|||
| Place Of Origin: | Guangdong, China | Model Number: | GYTC8A |
|---|---|---|---|
| Type: | Outdoor Fiber Optic Cable | Number Of Conductors: | ≥ 10 |
| Fiber Type: | G652D Single Mode Or As Your Request | Length: | As Required |
| Color: | Customized | Loose Tube: | PBT |
| Central Strength Member: | Steel Wire | Jacket: | PE,MDPE,LSZH,PVC |
| Package: | Wooden Drum/Customized | Application: | Aerial,Overhead |
| Oem: | Available | ||
| High Light: | Outdoor Aerial Fiber Optic Cable,Figure 8 Aerial Fiber Optic Cable |
||
Product Description
Product Description:
Features:
Specification:
| item | value |
| Model Number | GYTC8A |
| Type | Outdoor Fiber Optic Cable |
| Place of Origin | Guangdong,China |
| Brand Name | jiqian |
| Structure | multi loose tube |
| Number of Conductors | ≥ 10 |
| Fiber count | 2-144 Cores |
| Fiber Type | G652D Single mode or as your request |
| Central strength member | steel wire |
| Loose tube | Jelly filled |
| Loose tube | PBT |
| Armor | APL |
| Jacket Sheath | PE |
| Color | Black or as your need |
| Package | Plywood Reel/customized |
| Application | Aerial,Overhead |
| operating temperature | -40 to +70 |
| Certification | CE/ROHS/ISO9001 /ANATEL |
Optical Characteristics:
| G.655 | 50/125μm | 62.5/125μm | ||
| G.652 | ||||
| Attenuation | '@850nm | ≤3.0 dB/km | ||
| (+20℃) | '@1300nm | ≤1.0 dB/km | ||
| '@1310nm | ≤0.34 dB/km | ≤0.40 dB/km | ||
| '@1550nm | ≤0.21 dB/km | ≤0.23 dB/km | ||
| '@850nm | ≥500 MHz·km | |||
| '@1300nm | ≥1000 MHz·km | |||
| Numerical Aperture | 0.200±0.015NA | |||
Technical parameters:
| Cable Type | Fiber Count | Cable Diameter | Cable Weight Kg/km | Supporting Wire Spec | Connection Diameter | Tensile Strength N | Crush Resistance | Bending Radius mm |
| GYTC8A-2～60 | 2～60 | 9.5×18.3 | 218 | ф1.0mm×7 | High * width 3.0×2.5 | 4000/7500 | 500/1000 | 15D/30D |
| GYTC8A-62～72 | 62～72 | 10.5×19.3 | 240 | ф1.0mm×7 | High * width 3.0×2.5 | 4000/7500 | 500/1000 | 15D/30D |
| GYTC8A-74～96 | 62～72 | 12.5×20.3 | 280 | ф1.0mm×7 | High * width | 4000/7500 | 500/1000 | 15D/30D |
| GYTC8A-98～120 | 62～72 | 13.5×21.3 | 320 | ф1.0mm×7 | High * width 3.0×2.5 | 4000/7500 | 500/1000 | 15D/30D |
| GYTC8A-122～144 | 62～72 | 15.0×24.3 | 350 | ф1.0mm×7 | High * width 3.0×2.5 | 4000/7500 | 500/1000 | 15D/30D |
