Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath

Minimum Order Quantity : 1KM Packaging Details : wooden drum
Delivery Time : 3-5 working days ,it depends on your order Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability : 60000KM/month
Place of Origin: Guangdong, China Brand Name: Jiqian
Certification: ISO9001/CE Model Number: GYTC8S

Detail Information

Fiber Count: 2-144 Lift Time: More Than 25years
Fiber Type: G652D,G652B,G657A Application: Aerial
Factory: Yes Fiber Brand: YOFC
OEM: Yes
High Light:

steel wire Figure 8 Fiber Optic Cable

,

PE sheath Figure 8 Fiber Optic Cable

,

PE sheath figure 8 electrical cable

Product Description

Good Quality Self Support Aerial Steel Tape Amoured GYTC8S Figure 8 Fiber Optic Cable





Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 0

Structure
1.Steel wires----self support
2.Web
3.Central strength member----steel wire
4.Steel tape ----armoured
5.Outer sheath----PE
6.Optic fiber----250µm





Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 1

Features:

  • 1.Low dispersion and attenuation.

    2.Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and
    environmental characteristics.

    3.The armoring of corrugated steel tape makes cable have nice moisture resistance and crush resistance performance.


    4.Small cable diameter, light cable weight, self-supporting, easily to install
Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 2

Applicable fields:

Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 3




Technical Data

Cable Type
Fiber Count
Cable Diameter mm
Cable Weight kg/km
Tensile Strength
Crush Resistance
Bending Radius
Long/Short Term
Long/Short Term
Static/Dynamic
N
N/100mm
mm
GYTC8S
2-30
9.8*18.5
166
2000/6000
300/1000
10D/20D
GYTC8S
32-48
10.6*19.3
180
2000/6000
300/1000
10D/20D
GYTC8S
50-60
10.6*19.6
190
2000/6000
300/1000
10D/20D
GYTC8S
62-72
11.3*20.3
217
2000/6000
300/1000
10D/20D
GYTC8S
74-84
12.7*21.7
252
2000/6000
300/1000
10D/20D
GYTC8S
86-96
12.7*21.7
252
2000/6000
300/1000
10D/20D



Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 4



There are twelve fiber color code.They are A grade fiber.

Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 5








Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 6

We are fiber cable manufacturer.We have a factory.



Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 7

Package: Wooden reel, 1000m/reel, 2000m/reel, 3000m/reel, customer's requirements are also welcomed



Steel Wire Strength GYTC8S Figure 8 Fiber Optic Cable PE Sheath 8

We go to exhibitions. We have rich foreign trade experience, you can save purchasing time.

Don't hesitate to contact me. Whatsapp:+86 18122383351





FQA



Q1.Are you the real manufacturer?
We are the real manufacturer with 10 year’s history.


Q2.What’s the MOQ?
The MOQ of Fiber Optic cable is 1km.


Q3.What’s delivery time?
The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.


Q4.How to Store the Optical Fiber Cable Properly?

Store the drum indoor before using, the drum should place sideways not on the end.


Q5. Can you supply customized products and logo?
Yes. We supply OEM service.


Q6.What’s your payment terms?
We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70% before shipment.
