Name: Aerial Figure 8 Self-supporting GYXTC8S GYTC8A GYXTC8Y GYTC8S Fiber Optic Cable With Steel Wire Messenger
Brand: Guangzhou Jiqian Fiber Optic Cable Co., Ltd.
SKU: GYTC8S/GYTC8Y/GYTC8A
Price: 480.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Fiber Type: Single Mode & Multi Mode

Oem: Available

Application: Aerial

Number Of Conductors: 12 24 48 96

Structure: Stranded Loose Tube

Operating Temperature: -40 ~ +60 C

Length: 1KM OR 2KM OR 500M

Highlight:

GYXTC8Y Fiber Optic Cable

GYXTC8S Fiber Optic Cable

Basic Infomation

Place of Origin: CHINA

Brand Name: jiqian

Certification: ISO/CE/ROHS

Model Number: GYTC8S/GYTC8Y/GYTC8A

Payment & Shipping Terms

Packaging Details: wooden drum

Delivery Time: 2-4day

Payment Terms: Western Union, T/T, L/C

Supply Ability: 100km per 2 day

Gallery

Aerial Figure 8 Self-supporting GYXTC8S GYTC8A GYXTC8Y GYTC8S Fiber Optic Cable With Steel Wire Messenger

Product Description

GYTC8S Figure 12 24 Stranded Loose Tube Messenger Wire Aerial outdoor Fiber Optic cable

Self-Supporting Aerial 48 Core GYTC8S Outdoor Fiber Optical Communication Cable

figure-8 optical fiber cable with metallic central strength member of steel wire/strand and moisture barrier inner sheath incorporating steel messenger wire suitable for overhead installation as pole-to-pole or pole-topremises.Tubes contain optical single-mode or multimode fibers color coded as per the color coding scheme.

Introduce some detail to you :

Structure:

Figure 8 non armoured fiber cable consists of :

1.Stranded loose tube

2.Steel wire strength member

3.Core filler compound

4.Fillers

5.Phosphating or Galvanized steel wire

6.PE sheath

Standards and Certificate:

Fiber optical cable complies with Standard YD/T 769-2003,IEC60794-1

Certificate: ISO9001

Characteristics
1 Good mechanical and temperature performance
2.High strength loose tube that is hydrolysis resistant
3.Special tube filling compound ensure a critical protection of fiber

Optical Characteristics:

		G.652D	50/125μm	62.5/125μm
Attenuation (+20℃)	@850nm		≤3.0 dB/km	≤3.0 dB/km
	@1300nm		≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km
	@1550nm	≤0.22 dB/km
Bandwidth (Class A)	@850nm		≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm		≥1000 MHz·km	≥600 MHz·km
Numerical Aperture			0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength λcc		≤1260nm

Printing :

1: we support OEM

2: And print your company name on drum or jacket

3: Customize Jacket Color .

Aerial Figure 8 Self-supporting GYXTC8S GYTC8A GYXTC8Y GYTC8S Fiber Optic Cable With Steel Wire Messenger 5

Our factory :

Aerial Figure 8 Self-supporting GYXTC8S GYTC8A GYXTC8Y GYTC8S Fiber Optic Cable With Steel Wire Messenger 6

Aerial Figure 8 Self-supporting GYXTC8S GYTC8A GYXTC8Y GYTC8S Fiber Optic Cable With Steel Wire Messenger 7

FAQ:

1. Are you the real manufacturer?

Yes, we are factory in guangzhou china, welcome to visit us!

2. what is your minimum quantity?

1KM. We support new project of our customers, trial order is available

3.Can I get a sample?

Yes, we provide FREE sample and you just need to pay for express freight.

4.What about Payment?

L/C,T/T,Western Union and Paypal are acceptable.

5.Delivery time?

Generally 3-7 working days, also it is according to qty.

6.Can you supply customized products and logo?

Yes, we supply OEM&ODM service, pls feel free to contact. Aerial Figure 8 Self-supporting GYXTC8S GYTC8A GYXTC8Y GYTC8S Fiber Optic Cable With Steel Wire Messenger 8
